Material Information

Aluminum Alloy + High-Strength Engineering Plastic

Vertical Dimensions (L x W x H)

Approx. 610 mm x 370 mm x 406 mm

Unfolded Dimensions (L x W x H)

680 mm x 370 mm x 115mm

Weight (including battery): 15kg

Operating Temperature: 0°C-40°C

Protection Rating: IP32

Charging Time: ≤2 hours ~ <2 hours Battery Life: 1-2 hours Range: 6km Performance Parameters Basic Computing Power: 8-core high-performance CPU Maximum Power Consumption: 3500W Maximum Speed: 3.7m/s Maximum Load Capacity: ≥8kg, 28kg Continuous Climbing Height: 16cm Stair Climbing Height: 16cm Maximum Climbing Angle: 30° Jump Height: 35cm Ground Clearance: 35cm Actuator Type: High Power Density Motion Unit Maximum Joint Torque: 48kJ N·m Aluminum alloy precision joint motors: 12 Joint range of motion (torso): 28°~28° Joint range of motion (thigh): 170°~66° Joint range of motion (lower leg): 35°~156° Camera field of view: DFOV122®, HFOV111*, VFOV70° Sensor: IMU: Standard Function list: Standard movements: Standing, lying down, damped movement, pitch, height adjustment, horizontal rotation Special skills: Forward jump, upward jump, two-legged stand, backflip, greeting, etc. Real-time image transmission: Supported Secondary development: Not supported Function expansion interface: None Battery: Nominal capacity 5Ah, rated capacity 4.6Ah, voltage 43.2V Accessories: Adapter
